Manufactured with the best components and the most powerful stepper motor on the market, this KOSO tachometer is the perfect accessory for all motorcycles. Its large dial and illumination make it very easy to read.
TIP:Fits perfectly into the steering head cover of the PX old models (until approx. 1984). The adjustment buttons are then slightly covered by the collar of the steering head cover. Furthermore the tachometer is not as flush as the original speedometer. But it is not as deep as the original one, so it could be fitted further into the cover individually.
|
tachometer |
display range: 0~10000 rpm |
|
response time |
0.5 seconds |
|
rpm Settings Input signal number |
0.5, 1~6 |
|
r/min Pulse input |
HI (CDI) |
|
Lo (Contacts) |
|
|
Backlight brightness |
5 different values Level available |
|
Each individual level comprises 20% |
|
|
switching flash |
adjustment range: 0~10000RPM |
|
effective temperature range |
-10~ + 60°C |
|
Standard |
JIS D 0203 S2 |
|
Dimensions |
120 x 68.5 x 44.1 mm |
|
weight |
approx. 127.3 g |
